APC SMT2200RMI2U
APC Smart-UPS : RackModel
Output
Output power capacity 1.98 KWatts / 2.2 kVA
Max Configurable Power (Watts) 1.98 KWatts / 2.2 kVA
Nominal Output Voltage 230V
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Output Frequency (sync to mains)
47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
Other Output Voltages 220, 240
Topology Line Interactive, Waveform type Sine wave
Output Connections
(8) IEC 320 C13 (Battery Backup), (1) IEC 320 C19 (Battery Backup)
Transfer Time 4ms typical : 8ms maximum
Input
Nominal Input Voltage 230V
Input frequency 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
British BS1363A, IEC-320 C20, Schuko CEE 7/EU1-16P
Cord Length 2meters
Input voltage range for main operations 160 - 286V
Input voltage adjustable range for mains operation 151 - 302V
Number of Power Cords 1
Other Input Voltages 220, 240
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time 3hour(s)
Replacement Battery RBC43 RBC Quantity 1
Communications & Management
Interface Port(s) USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : configurable delays
Available SmartSlot Interface Quantity 1
Surge Protection and Filtering
Surge energy rating 375Joules
Physical
Maximum Height 86mm , Width 480mm, Depth 683mm
Rack Height 2U, Net Weight 42.31kg
Environmental
Operating Environment 0 - 40 ฐC
Operating Relative Humidity 0 - 95 %
Operating Elevation 0-3000 meters
Storage Temperature -15 - 45 ฐC
Storage Relative Humidity 0 - 95 %
Storage Elevation 0-15000meters
Audible noise at 1 meter from surface of unit 55.0dBA
Online thermal dissipation 215.0BTU/hr
Approvals
CE, EAC, EN 60950, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE
Warranty 3 Yrs./ Onsite Swap
