Liebert  GXT-1000MTPLUS

Product Description

part nunber gxt-1000mtplusc230
Technology     True Online
Capacity (VA/W)     1000/900
Input Parameters
Frequency Range    40Hz ~ 70 Hz
Phase    Single phase with ground
Power Factor    = 0.99 @ 220 to 230 VAC (input voltage)

Voltage Range

Low Line Transfer    160 VAC / 140 VAC / 120 VAC / 110 VAC ฑ 5 %
( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line Comeback    175 VAC ฑ 5 %
High Line Transfer    300 VAC ฑ 5 %
High Line Comeback    290 VAC ฑ 5 %

Output Parameters

Output Voltage    208/220/230/240VAC
AC Voltage Regulation    ฑ 3% (Batt. Mode)
Frequency Range    47 to 53 Hz or 57 to 63 Hz (Synchronized Range)
Frequency Range (Batt. Mode)    50 Hz ฑ 0.25Hz
Overload    100% to 110%: audible warning
110% to 130%: UPS shuts down in 30 seconds at battery mode or
transfers to bypass mode when the utility is normal.
>130%: UPS shuts down immediately at battery mode or
transfer to bypass mode when the utility is normal.
Current Crest Ratio    3:1
Harmonic Distortion    = 3 % THD (Linear Load)
= 6 % THD (Non-linear Load)
Waveform (Batt. Mode)    Pure Sinewave

Efficiency


AC Mode    ~ 85%
Battery Mode    ~ 83%
Transfer Time
AC Mode to Batt. Mode    Zero
Inverter to Bypass    4 ms (Typical)
Battery Charger (Standard Model)
Battery Type    12 V / 7 AH
Numbers    3
Charging Current    4.0 A or 8.0 A(max.)
Charging Voltage    41.0 VDC ฑ 1%

Physical Parameters

Dimension, D X W X H    220 x 145 x 397
Net Weight (kgs)    13

Emvironmental Parameters

Operation Humidity    20 to 90 % RH @ 0 to 40ฐC (non-condensing)
Noise Level    Less than 55dBA @ 1 Meter
Management    4.0 A or 8.0 A(max.)
Smart RS-232 or USB    Supports Windows 98/2000/2003/XP/Vista/2008/ 7, Linux, and MAC

Optional SNMP

Power management from SNMP manager and web browser
3 Yrs OnSite Replacement By Vertiv

Features

Double conversion on-line technology
Compact tower design
Standard models and long backup models available
Extended runtime capabilities by building up additional battery resources
Flexible (site specific) battery configuration
Standard model comes with internal battery
Generator-compatible with wide input frequency range (40 to 70 Hz)
0.8 output power factor
Class A electromagnetic interference (EMC)
Ultra wide input voltage range
High input power factor & low THDi
Emergency power off (EPO)
Configurable to energy saving mode (ECO)
LCD display for operational convenience and status / fault information
Multiple AC output interfaces via IEC standard sockets with Programmable output
Remote Monitoring is available through USB / RS232, and optional via dry contacts and SNMP

GXT-1000MTPLUS230

PRODUCT OVERVIEW

Power Rating 1000VA / 800W
Output Voltage 208/220/230/240VAC

GXT-1000MTPLUS230

The Liebert® GXT MT+ features best-in-class power protection for critical applications with the use oftrue on-line double conversion technology. The Liebert® GXT MT+ has a comprehensive specification that provides a higher level of availability to the IT equipment. It satisfies safety criteria and electromagnetic compatibility standards while offering intelligent monitoring and network management functions. This high performance UPS with proven reliability is available in a compact tower design.

Best Suited For:

Banking, Financial and Insurance Broadcast and Entertainment Education Government Healthcare Retail and Wholesale

Benefits

The Liebert GXT-MT Plus is ideally suited for:

Small Size Data Center
Telecommunication Equipment
VoIP
Small Offi ce Network
Computer Rooms
Process Automation Equipment
Network Storage Devices

What's in the box?

UPS Module
Battery Connection Cable only with Long Backup models
RS 232 Cable / USB Cable
UPS Monitoring Software (to be downloaded from internet)
User Manual
IEC Output cables x 2
CEE7/7 to IEC-C20 and BS1363 to IEC-C20 input power cord (3KVA model
