[BX950MI-MS]



APC Back-UPS 950VA, 230V, AVR, 2 universal & 2 IEC outlets
part number bx950mi-ms

Main Input Voltage 230 V

rated power in 520 W
rated power in 950 VA
nb of power socket outlets 2 universal,2 IEC 60320 C13
cable length 1.22 m
number of cables 1
battery type Lead-acid battery
General provided equipment,User manual

max runtime 120 min
Number of power module free slots 0
Number of power module filled slots 0
redundant No
Physical

colour Black
height 16 cm width 12 cm depth 35.5 cm
net weight 6.1 kg
mounting preference No preference
mounting mode Not rack-mountable
two post mountable 0
USB compatible No
Input

network frequency 50/60 Hz +/- 5 Hz auto-sensing
input voltage limits 140...300 V
Input Power Factor at Full Load 0.54
Output

Maximum configurable power in 520 W
output frequency  50/60 Hz +/- 1 Hz sync to mains
UPS type Line interactive
Wave type  Stepped approximation to a sinewave
full load runtime 00:01:00 480 W
half load runtime 00:06:30 240 W
Maximum configurable power in VA  950 VA
Transfer time 6 ms typical : 10 ms maximum
Conformance

product certifications CE
equipment protection policy
Lifetime : 50000 euros
Environmental

ambient air temperature for operation 0…40 °C
relative humidity 0…95 % non-condensing
operating altitude 0...3000 m
ambient air temperature for storage -15…40 °C
storage Relative Humidity 0…95 % Non-condensing
storage altitude 0…3000 m
acoustic level 40 dBA
IP degree of protection IP20
Batteries

number of battery filled slots 0
number of battery free slots 0
Battery recharge time 8 h
battery voltage 12 V
Battery power in VAH 97 VAh runtime
battery life  3…5 year(s)
Replacement battery RBC17

Battery graph comments
Curve fit to measured runtime data. All measurements taken with new,
fully charged batteries, at typical environmental conditions,
with no electrical input and balanced resistive load (PF = 1.0) output.
extended runtime 0
Communications & Management
control panel  LED Status display with on line : on battery
alarm  Alarm when on battery : distinctive low battery alarm
Surge Protection and Filtering
Surge energy rate 273 J
Data line protection
RJ45 10/100/1000 Base-T Ethernet protection
Warranty 2 years repair or replace


ซอฟต์แวร์ที่เข้ากันได้
PowerChute Personal Edition v3.1


APC™ BackUPS ™ BX series is a cost effective power - bx950mi-ms

protection solution for home and home office environments.
The series comprehensive VA range with premium features further enables single UPS capabilities
Ideal Power Protection for the following environments and devices:
Home office - work from home & remote learning devices
Home Entertainment - Living room essentials
Smart Home - loT electronics

Battery backup is key to home continuity
The Electronic devices you reply on for communication, security and entertainment depend on a stable network connection.
Ensure reliable uptime and clean power for your critical devices.
Comprehensive Power Capacity Range
Models ranging from 750VA2200VA; choose a solution aligned with your specific application and runtime needs
Visibility and Manageability Software
In the event of an extended power outage, prevent potential data loss or corruption with PowerChute Personal Edition Software
Form Factor:
Compact for office and business spaces (BX750MIOutlets 3MS: 160 x 120 x 355 mm).
Outlets
3 - 5 battery backup with surge protection outlets
Functional ease-of-use
Front panel LED green lights to easily tell the functional status
1Gb Network Protection
Safeguards your equipment and valuable files from “back door” surges traveling along data lines without
sacrificing internet speed
Automatic Voltage Regulation (AVR)
Instantly corrects incoming utility power without utilizing the battery, saving the battery for when it is needed most

APC Back-UPS 950VA, 230V, AVR, 2 universal & 2 IEC outlets - part number bx950mi-ms
ราคา 5,115 บาท
( #5,473 บาท vat )
APC BX series - apc bx750mi-ms, apc bx950mi-ms, apc bx1200mi-ms, apc bx1600mi-ms, apc bx2200mi-ms
