BU1000ELCD | Cyberpower | BU Series | Uninterruptible Power Supply (Ups)
GENERAL
Phase Single Phase
Form Factor Desktop
UPS Topology Line-interactive
Energy Saving Technology GreenPower UPS™ Bypass Technology
INPUT
Generator Compatibility Yes
Nominal Input Voltage ( Vac ) 230 ± 10%
Input Voltage Range ( Vac ) 165 ~ 280
Input Frequency ( Hz ) 50 ± 5, 60 ± 5
Input Frequency Detection Auto-sensing
Rated Input Current ( A ) 4.55
Input Connector Type NEMA 5-15P
Power Cord Length (m.) 1.2
OUTPUT
Capacity (VA) 1000
Capacity (Watts) 630
On Battery Waveform Simulated Sine Wave
On Battery Voltage(s) ( Vac ) 230 ± 10%
On Battery Frequency ( Hz )50 ± 1%, 60 ± 1%
Automatic Voltage Regulation (AVR) Single Boost, Single Buck
Overload Protection Circuit Breaker
Outlet(s) - Total 4
Outlet Type AS x 4
Outlet(s) - Battery & Surge Protected 4
Typical Transfer Time ( ms ) 4
BATTERY
Runtime at 60W ( min ) 74
Runtime at 90W ( min ) 45
Runtime at 200W ( min ) 14
Typical Recharge Time ( Hours ) 8
Start On Battery Yes
User-replaceable No
Battery Type Sealed Lead-acid
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )150
EMI/RFI Filtration Yes
MANAGEMENT & COMMUNICATIONS
LCD Panel Yes
LCD Information Display
Power Status, Battery Status, Load Status
LED Indicators : Power On, Line Mode, Battery Mode, Low Battery
Audible Alarms Battery Mode, Low Battery, Overload, UPS Fault
PHYSICAL
Enclosure Construction Plastic
Color Black
PHYSICAL SIZE - Dimensions (WxHxD) (mm.) 190 x 110.5 x 290
Weight (kg.) 7.0
ENVIRONMENTAL
Operating Temperature (°C) 0 ~ 40
Operating Relative Humidity (Non-condensing) ( % ) 0 ~ 90
Storage Temperature (°C) -20 ~ 50
Storage Relative Humidity (Non-condensing) ( % ) 0 ~ 90
Storage Elevation ( feet/meters ) 0-9,843 feet (0-3,000 meters)
Online Thermal Dissipation ( BTU/hr ) 45
Audible Noise at 1.5M from Surface of Unit ( dBA ) 40
CERTIFICATIONS RoHS Yes
2 years warranty - onsite service
CyberPower BU1000ELCD provides home and office users with a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes, brownouts and other power irregularities. The product adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilized AC power output.
The patented GreenPower UPS™ Bypass design achieves ultra-low power consumption to reduce energy costs, and allows a lower operation temperature which extends battery lifespan. Configurable alarm allows users to switch the audible alarm on or off during battery mode to avoid unnecessary disturbances. Its desktop design allows users to place it easily on desks or other tight spaces.
FEATURES
Energy Saving Technology
Generator Compatible
Overload Protection
EMI and RFI Filtration
Automatic Voltage Regulation (AVR)
LED Status Indicator
Surge and Spike Protection
Configurable Alarm
WHAT'S IN THE BOX
BU1000ELCD UPS, User's Manual
* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.
Cyberpower BU1000ELCD ทำให้กล้องวงจรปิด ทำงานได้แม้ไฟดับ
ให้กล้องวงจรปิด ทำงานต่อได้ ไม่พลาดทุกช็อต ที่สำคัญมาพร้อมฟังก์ชัน
- เทคโนโลยี Line Interactive
- อัตราการทำงาน 1000VA/630W
- สำรองไฟฟ้าได้ 70 นาที ที่โหลด 60 วัตต์
- มีช่องไฟขาออก 4 ช่อง (ช่องสำรองไฟและช่องกันไฟกระชาก)
- Energy Saving Technology ลิขสิทธิ์เฉพาะ ที่สามารถลดการสูญเสียพลังงานในตัวเครื่องสำรอง
- Automatic Voltage Regulation (AVR) ระบบควบคุมแรงดันไฟฟ้าอัตโนมัติ ที่ช่วยควบคุมแรงดันไฟฟ้าต่ำ และแรงดันไฟฟ้าเกิน
- Generator Compatible สามารถรับไฟจากเครื่องปั่นไฟมาใช้ได้โดยไม่มีปัญหากับตัวเครื่องและโหลดที่ต่ออยู่ เพราะเครื่องปั่นไฟจะมีแรงดันกับความถี่ที่กว้างและไม่นิ่ง
- LCD Status Display หน้าจอ LCD บอกสถานการทางานของเครื่อง UPS, บอกปริมาณของ Load ที่ใช้งานผ่าน UPS, บอกปริมาณของแบตเตอรี่, บอกแรงดันไฟขาเข้า และขาออก จากUPS และบอกเวลาที่สารองไฟได้ในขณะนั้น
- รับประกันสินค้านานถึง 2 ปี รวมถึงแบตเตอรี่ด้วย
- บริการหลังการขาย On-Site Service





ลูกค้าสามารถติดต่อ เพิ่มเติมได้ที่ 088 758 4005 080 964 2745 096 308 9747 088 758 4003 088 758 4005 080 964 2745
