VP700ELCD | Cyberpower | VP Series | Uninterruptible Power Supply (Ups)
Phase Single Phase
Form Factor Tower
UPS Topology Line-interactive
Energy Saving Technology GreenPower UPS™ Bypass Technology
INPUT
Generator Compatibility Yes
Nominal Input Voltage ( Vac ) 230 ± 10%
Input Voltage Range ( Vac ) 167 ~ 295
Input Frequency ( Hz ) 50 ± 5, 60 ± 5
Input Frequency Detection Auto-sensing
Rated Input Current ( A ) 3.04
Input Connector Type IEC C14
Detachable Power Cord Plug Type NEMA 5-15P x 1
Power Cord Length (m.) 1.5
OUTPUT
Capacity (VA) 700
Capacity (Watts) 390
On Battery Waveform Simulated Sine Wave
On Battery Voltage(s) ( Vac ) 230 ± 10%
On Battery Frequency ( Hz ) 50 ± 1%,60 ± 1%
Automatic Voltage Regulation (AVR) Single Boost, Single Buck
Overload Protection Circuit Breaker
Outlet(s) - Total 3
Outlet Type AS x 3
Outlet(s) - Battery & Surge Protected 3
Typical Transfer Time ( ms ) 4
BATTERY
Runtime at Half Load ( min ) 10
Runtime at Full Load ( min ) 1
Typical Recharge Time ( Hours ) 8
Start On Battery Yes
User-replaceable No
Battery Type Sealed Lead-acid
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules ) 450
EMI/RFI Filtration Yes
Phone/Network Protection RJ11/RJ45 (Combo) 1-in, 1-out
MANAGEMENT & COMMUNICATIONSLCD Panel Yes
LCD Information Display
Operation Type, Power Status, Battery Status, Load Status, Fault & Warning,
Other Information
LCD Setting & Control
Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning
LED Indicators
Power On
HID Compliant USB Port(s) 1
Audible Alarms
Battery Mode, Low Battery, Overload, UPS Fault
Management Cable ( pcs ) USB Cable x1
Ethernet Data Transmission Speed Up to 1Gbps
Power Management Software PowerPanel Personal (Recommended)
PHYSICALEnclosure Construction Plastic
Color Black
PHYSICAL SIZE - Dimensions (WxHxD) (mm.) 100 x 227 x 260
Weight (kg.) 5.14
ENVIRONMENTAL
Operating Temperature (°C) 0 ~ 40
Operating Relative Humidity (Non-condensing) ( % ) 0 ~ 90
Operating Elevation ( feet/meters ) 0-9,843 feet (0-3,000 meters)
Storage Temperature (°C) -20 ~ 50
Storage Relative Humidity (Non-condensing) ( % ) 0 ~ 90
Storage Elevation ( feet/meters ) 0-9,843 feet (0-3,000 meters)
Online Thermal Dissipation ( BTU/hr ) 9.5
Audible Noise at 1.0M from Surface of Unit ( dBA ) 40
CERTIFICATIONS
RoH, SCE, RCM Yes
WARRANTY
Product Warranty Period (Year) 2
Battery Warranty Period (Year) 2
CyberPower VP700ELCD offers home and office users a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes, brownouts and other power incidents. Designed with GreenPower UPS™ Technology to improve operating efficiency and to minimize energy consumption, users can enjoy significant energy cost savings over conventional UPS systems. The UPS provides Automatic Voltage Regulation (AVR) to maintain safe voltage for connected equipment.
The UPS provides multifunctional LCD readout to display clear power and battery conditions. The product features data line protection with high-speed transmission to safeguard phones, network and communication equipment against surge/spike as well as supply 1Gbps speed to transmit data. The UPS is also compatible with PowerPanel Power Management Software to achieve real-time monitoring and configuration.
FEATURES
Line-interactive UPS Topology,Generator Compatible,Automatic Voltage Regulation (AVR),High-speed Ethernet Data Transmission
Surge and Spike Protection, PowerPanel Management Software
Energy Saving Technology, Simulated Sine Wave Output, LCD Status Display,USB Connectivity Port,Serial Connectivity Port
WHAT'S IN THE BOX
VP700ELCD UPS USB Cable, User's Manual, Product Registration Card
* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.
Cyberpower VP700ELCD รุ่นนี้ ของเขาดีจริง ดียังไง ทำไมถึงต้องใช้❓ เรามาดูกัน VP700ELCD ที่บอกว่าดีเพราะเขามี
- เทคโนโลยี Line Interactive
- อัตราการทำงาน 700VA/390W
- มีช่องไฟขาออก 3 ช่อง (ช่องสำรองไฟและช่องกันไฟกระชาก)
- Energy Saving Technology ลิขสิทธิ์เฉพาะ ที่สามารถลดการสูญเสียพลังงานในตัวเครื่องสำรองไฟฟ้า มีประสิทธิภาพในการช่วยประหยัดพลังงาน
- Automatic Voltage Regulation (AVR) ระบบควบคุมแรงดันไฟฟ้าอัตโนมัติ ที่ช่วยควบคุมแรงดันไฟฟ้าต่ำ และแรงดันไฟฟ้าเกิน
- Generator Compatible สามารถรับไฟจากเครื่องปั่นไฟมาใช้ได้โดยไม่มีปัญหากับตัวเครื่องและโหลดที่ต่ออยู่ เพราะเครื่องปั่นไฟจะมีแรงดันกับความถี่ที่กว้างและไม่นิ่ง
- LCD Status Display หน้าจอ LCD บอกสถานการทางานของเครื่อง UPS, บอกปริมาณของ Load ที่ใช้งานผ่าน UPS, บอกปริมาณของแบตเตอรี่, บอกแรงดันไฟขาเข้า และขาออก จากUPS และบอกเวลาที่สารองไฟได้ในขณะนั้น
- มี Surge and spike protection ระบบป้องกันไฟกระชาก ที่มาจากความผิดปกติของระบบส่งกำลัง หรือฟ้าผ่าที่มาตามสายไฟฟ้าได้
ไม่ใช่แค่สามารถทำงานได้อย่างต่อเนื่อง แต่ยังช่วยป้องกันเครื่องใช้ไฟฟ้าจากไฟตก ไฟดับ ไฟกระชากอีกด้วย
ไม่ว่าจะเป็น คอมพิวเตอร์สำหรับเกมเมอร์ TV หรือ Play Station 5 ก็เอาอยู่




ลูกค้าสามารถติดต่อ เพิ่มเติมได้ที่ 088 758 4005 080 964 2745 096 308 9747 088 758 4003 088 758 4005 080 964 2745
Cyberpower VP700ELCD
ffice hours : 8:30 - 17:30 ( Monday - Friday )
Tel 0 2952 7823
เครื่องสำรองไฟ cyberpower vp700elcd รุ่นเล็ก ขนาดไม่ใหญ่ สำรองไฟ ได้ มากสุดถึง 390 วัตต์ มีปลั๊กด้านหลัง 3 ช่องเสียบ ทรงตั้ง ราคาพิเศษ ติดต่อ ได้เลยค่ะ
