Delta UPS - Amplon Family


RT Series, Single Phase ( Rack/TOWER )
RT-1000VA-3Y or RT-1K Model
Power Rating  1kVA/0.9KW ( true online double-conversion )
INPUT

Nominal Voltage  200*, 208*, 220, 230, 240 Vac
Voltage range 120 ~ 280 Vac
Frequency 50/60 Hz +/- 10 Hz
Power Factor > 0.99 (full load)
Current Harmonic Distortion <5%
OUTPUT

Power Factor 0.9
Voltage  200*, 208*, 220, 230, 240 Vac
Voltage Regulation +/- 2% (linear load)
Frequency 50/60 Hz +/- 0.05 Hz
Current Harmonic Distortion < 3% (linear load)
Overload Capability < 105%: continuous;  < 105% ~ 125%:1 minutes;125% ~ 150%:30 seconds
Crest Factor  3:1
Receptacle IEC C13 x 3 x 2
EFFICIENCY

Online Mode 90%
ECO Mode 95%
BATTERY

Nominal Voltage 24 Vdc
Battery type : VRLA12v9Ah, 4 pcs ( 2 strings of 2 batteries )
Typical Backup Time 6.5 min
Recharge Time 3hrs to 90%
Charge Current 1.5A
AUDIBLE NOISE  <40 dBA
DISPLAY  LCD display and LED indicators
COMMUNICATION SMART Slot x 1, RS-232 Port x 1,
INTERFACES USB Port x 1, REPO x 1
CONFORMANCE SAFTEY & EMC CE/ RCM/ EN62040-1/ EN62040-2 Category C2
PHYSICA
L
Dimensions (Wx Dx H) 440 x 335 x 89 mm ( UPS, EXTERNAL BATTERY )
Weight 12 kgs FOR UPS, Weight 15 kgs FOR EXTERNAL BATTERY
ENVIRONMENT

Operating Temperature 0 ~ 40 C
Relative Humidity 5% ~ 95% (no condensing)
3 years warranty ( Onsite service )
Delta UPS - Amplon Family

RT Series, Single, Phase 1/2/3kVA
The Amplon RT 1-3kVA series is an online double-conversion UPS providing consistent pure sine-wave power to your critical equipment. It supports personal computers, networks, servers, VoIP and telecommunications. RT 1-3kVA series features an output power factor of 0.9 and best-in-class AC-AC efficiency up to 94% resulting in greater energy savings. Optional external battery pack can be connected for longer backup time to keep your applications safe and running smoothly at all times.

Features:
• True online double-conversion topology and zero transfer time to battery ensure high reliability
• Watch-dog design of DSP (Digital Signal Processor) increases reliability
• Cold-start capability provides temporary battery power when the utility power is out
• Fan failure detection alerts users to failed fans
• Hot swappable batteries ensure continuous operation even when batteries are being replaced
• Optional external battery pack for easy scaling of longer backup time
• High output power factor 0.9 provides more real power to critical loads
• High input power factor (pf > 0.99) and low harmonic distortion (iTHD < 5%) save upstream investment • Up to 94% AC-AC efficiency and 97% efficiency in ECO mode result in marked energy cost savings
• Wide input voltage range reduces the chance of using the battery and extends battery life
• Intelligent battery management sustains battery life and performance
• Fan speed control by load level maximizes efficiency and reduces audible noise
• Load segment control allows less-critical loads to be disconnected during blackouts and saves ba ttery runtime for important loads
• Convertible rack and tower configuration in 2U size cabinet
• Excellent local communications through rotatable LCD display
• Intelligent management software connectivity via RS232 or USB port
delta ups - is good for server, network, security, medical, pos, banking
